The BlackVue DR770X-1CH Plus features a Sony STARVIS™ Full HD image sensor for optimal image quality in any light. GPS recorder, built-in Wi-Fi, Cloud connectivity, impact and motion detection are also included.
Technical characteristics
Model name | DR770X-1CH |
Channel | 1CH |
Strong points | Full HD, Cloud, Wi-Fi, GPS, Sony sensor, external LTE module |
product dimensions | W 118.5mm (4.67”) x H 36mm (1.42”) / 103g (3.63oz) |
memory medium | microSD card up to 256 GB |
Recording Modes |
- Normal, - Event (Impact Detection / Speed ??Limit / Manual), - Parking Mode (Impact-Based Motion Detection + By Region, Timelapse + Events) |
Parking method | YES (with 3-wire hardwired cable – included) |
Voice event notifications in parking mode | YES |
Imaging sensor | Sony STARVIS™ CMOS sensor (approx. 2.1 MP) |
viewing angle | Diagonal 139°, horizontal 116°, vertical 61° |
Resolution Frame Rate |
Full HD @ 60fps * Frame rate may vary during Wi-Fi streaming |
Video Codecs | H.264 (AVC) |
Image quality and forward/reverse bit rate |
Highest (extreme): 25 Mbps Highest: 12 Mbps High: 10 Mbps Normal: 8 Mbps |
Free format | YES (adaptive) |
Event file overwrite protection | YES (up to 50) |
SD card failure alert | YES |
Scheduled restart | YES |
Video file extension | MP4 |
Wireless | Integrated (802.11 bgn) |
Cloud-ready | YES |
GPS | Integrated (Dual Band: GPS, GLONASS) |
Microphone | Integrated |
Speaker | Integrated |
Impact sensor | 3-axis acceleration sensor |
LED indicators | Recording LED, GPS/BT LED, LTE/Wi-Fi LED, Front Security LED, Proximity Detection Indication LED |
Button |
Button: Wi-Fi ON/OFF (Tap) Proximity Sensor: Mic ON |
